Model | QT4-22 Block machine | QT4-26 Block machine | QT4-35 Block machine |
Cycle Time(s) | 22s | 26s | 35s |
PCS/Mould (240*115*53mm) | 26pcs | 26pcs | 26pcs |
PCS/Shift (240*115*53mm) | 34000pcs | 28800pcs | 21000pcs |
Power(KW) | 19.5KW | 14.25KW | 11KW |
Dimension(mm) | 2950*2150*1600 | 2060*1730*2580 | 1120*1400*1700 |
Pallet Dimension(mm) | 850*550*30mm | 880*550*30mm | 880*480*30mm |
Raw material Workshop(m2) | 400m2 | 400m2 | 300m2 |
Working shed(m2) | 200m2 | 200m2 | 150m2 |
Working site(m2) | 2500m2 | 2500m2 | 1500m2 |
Power distribution(KW) | 45KW | 42KW | 30KW |
Water consumption | 6t/day | 5t/day | 4t/day |
Pallets needed (pcs) | 500-800pcs | 500-800pcs | 500pcs |
Weight(ton) | 3.0t | 2.4t | 1.1t |
Staff needed | 5~8 | 3~5 | 2~3 |
Warranty(months) | 18 months | 18 months | 18 months |
1.Pre-sale services: enthusiasm
Provide you the proper plan, process flow design and manufacturer equipment according to your special demand.
2.Sale services: servant
Send technicians to the job site for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3.After-sale services: faithfulness
To establish long term relationship with you, we will regularly pay return visit to customers.
QT4- 15 block making machine | QT4-26 block machine | QT4-35A automatic block machine | QT4-40 Brick Making Machine |
QT4-22 fully automatic block machine | QT4-25BH semi-auto hydraulic block machine | QT4-45 semi automatic block machine. | QT4-45 diesel Brick Making Machine |
